Telescopic Boom Mini Articulated Loader

Rated operating capacity over 2,000-lbs to lift more than any compact utility loader on the market, comparable to larger compact track and skid steer.
  • SV50H
Availability:
Quantity:

TPR


Butler SV50L Compact Utility Loader


  • Butler-exclusive telescoping arm design increases machine versatility with the ability to reach farther and dig below grade without even moving.

  • Rated operating capacity over 2,000-lbs to lift more than any compact utility loader on the market, comparable to larger compact track and skid steer loaders.





Butler® SV50L VS Dingo® TXL 2000 Telescoping

Machine has many selling points.  Here are some we captured.  Specifications vs TX2000 Toro


120"

Lift Height (Extended)


123"

98.5"

Lift Height (Retracted)


98.6"

5200#

Tip Weight



5715#

1820#

Operating Capacity @35% Tip

2000#

4810#

Machine Weight


6655#

48"

Machine Width


54"

93"

Machine Length (w/o bucket)

98.8"

50  Hp

Kohler or Yanmar


50HP Kubota

18.5 GPM

Aux Flow Rate


21.4 GPM


Travel Speed


5.4 MPH

10"

Track Width


11.8"

4.72 PSI

Ground Pressure


5.3 PSI


Bobcat Compact Universal Attach Plate

Dual

Aux Hydraulic Connections

Single






SV50L

Low Height

Mid Height

Max Height


NO TELE

5200#

3915#

5160#


MID TELE

3450#

2985#

4490#


MAX TELE

3140#

1510#

4200#


Butler SV50L versus Traditional Skid Steers:


Power to weight.  Tip at attachment plate is more than machine weight

Lift height to size.  Much smaller than skid steer with comparable lift height

The telecopic feature adds lift height but also reach

Quick easy on and off benefit of standing platform but with high performance of skid steer

Visibiltiy and Hearing much better to make safer to work around

Power to size.  It's power relative to its size and weight is better than skid steer

Almost as compact as other mini skid steers but much higher performance capacities

Butler SV50L versus Toro TX2000:



Toro is the bigger machine of the two.  TX2000 wins on tip at 5715# vs 5200#, lift height at 123" vs 120", Aux flow 21.4 vs 18.5 GPM

The SV50L is less Retail vs TX2000

The SV50L is much more compact at 48" vs 54" and 93" long verus 98.8" long

The SV50L has dual hydraulics so it is capable of operatign rotating grapples or tilting attachments

The SV50L weighs 4810# vs 6655# and lower ground pressure 4.72 PSI vs 5.3 PSI = less impact on lawns or sidewalks and easier transport

The SV50L is simpler and easier to work on




WARRANTY


For complete product warranty information contact Butler Customer Service.
